Gussets, Brackets, Tabs and Mounts


OCT 01-34114 - SLOTTED BODY TAB
.109" Steel, .26" x .76" w/Slotted Hole.

OCT 01-34115-10 - 1/2" GUSSET WITH ONE HOLE 10 PACK
Gussets are 1/8" thick steel. Used to strengthen roll cages and chassis tubing.
Gussets add support and strength to tubing joints when building roll cages or chassis mounts.

OCT 01-34116-10 - 1/8" GUSSET WITHOUT HOLE 10 PACK
Gussets are 1/8" thick steel. Used to strengthen roll cages and chassis tubing.
Gussets add support and strength to tubing joints when building roll cages or chassis mounts.

OCT 01-34117 - FLAT CHASSIS TAB - 1/2" HOLE
1 3/8" to Center of Hole. 3/16" Steel


OCT 01-34119 - REAR WING MOUNTING CHASSIS TAB 1/8" THICK
1 7/8" Long - 1/4" Hole 7/8" from Flat to Center of Hole

OCT 01-34120 - BRAKE LINE TAB 5/8" HOLE
.100 Steel - 3/4" Bottom to Center of Hole

OCT 01-34121 - UNIVERSAL CHASSIS TAB
16 gauge Steel with 1/4" Hole.





OCT 01-34126 - SADDLE GUSSETS FOR 1 1/2" TUBING
Gussets add support and strength to tubing joints when building roll cages or chassis mounts.

OCT 01-34128 - DOG EAR TAB 1/8" THICK 1/4" HOLE
1/8" Thick 1/4" Hole, Commonly used for body mounts.
